Location
MSE 0051B
Fees
2-Hour Training: $50
Regular Usage: $12.50 per 1/2 hour
-
Covid-19 Protocols for Renewed Access to Facilities
-
MSE Fee-For-Service facilities are reopened and will be following the latest campus guidelines on the return to campus website.
-
-
Instrument Specifications
Stage Accessory Reflection/Transmission Spinner Types of Samples Powder
Thin Films
Nanomaterials
Solid Objects
Application Phase ID
Quantification
2θ Range 0° to 168° 2θ Linearity Equal or better than ± 0.01°
-
Facility-provided Sample Holders
Membrane Holders Irregular Holders Round Holders -
User-provided Consumables
Modeling Clay for Irregular Sample Holder: Storehouse Description: SARGENT ART 22-4096 1LB MODELING CLAY,WHITE (Stock #: 48702-108) Silicon Zero-Background Plate for Membrane and Irregular Sample Holder (for powders and thin films): MTI Corp: Zero Diffraction Platea 32 mm Dia. x 2.0 mm t, Si Crystal for XRD sample ($150) Silicon Zero-Background Plate for Irregular Sample Holder (useful for powders): Warning: X-ray beam shall be 5 mm dia or less (current installed beam mask is 10 mm) and hit in the center of sample when you use cavity zero diffraction plate! Otherwise the edge may result in a peak. USE AT YOUR OWN RISK!
-
Useful Docmentation & Software
UCR training and operators guide UCR MSE XRD Training Notebook rev. 4.2 (last updated February 20, 2019) MIT High Score Plus guide MIT HighScore Plus Guide PANalytical Data Viewer v6.1 Software PANalytical Data Viewer v6.1 Zip File Powder X-ray Diffraction Textbook Rigaku's Introduction to Powder X-ray Diffraction Textbook -
Training Videos
-
Access to XRD
-
Only trained users are allowed to operate the equipment
-
Trained users are NOT ALLOWED to train anyone else on the equipment
-
Trained users are NOT ALLOWED to bring in any unauthorized visitors even if the visitors are observing the trained user without prior notification to the lab manager
-
All visitors MUST complete the following 4 training modules via UC Learning and inform the lab manager prior to entering the lab as an EH&S requirement
-
Laboratory Safety Fundamentals
-
Hazardous Waste Management
-
Radiation Safety For Users of Radiation Producing Machines
-
Compressed Gas Safety
-
- E-mail a copy of your visitor's training transcript to facilities manager Perry Cheung (pcheung@engr.ucr.edu)
-
-
Training Request for XRD
-
Have your PI send the facilities manager, Perry Cheung (pcheung@engr.ucr.edu), an email indicating approval for your training
-
Complete the following 4 training modules via UC Learning
-
Laboratory Safety Fundamentals
-
Hazardous Waste Management
-
Radiation Safety For Users of Radiation Producing Machines
-
Compressed Gas Safety
-
-
Review the XRD Policies and Regulations
-
Fill out the XRD COA Authorization Form with PI signature and your departmental FA or FAO signature
-
Email a copy of your training transcript and signed Authorization Form to facilities manager Perry Cheung (pcheung@engr.ucr.edu)
-
Send a recent headshot photo of yourself to the facilities manager (a simple JPEG using your phone will suffice)
-
You will receive an email in a few days with your username and temporary password to reserve time on our Faces scheduling system (Group: ucr_xrd)
-
Check available 2 hour blocks on Faces and arrange a time with the facilities manager for training
-
Reserve a 2 hour block on Faces for the "XRD" resource
-
Review ALL XRD Training Videos (see above) first before your actual in-person training session
-
Meet outside lab manager’s office (MSE 311) on agreed training day and time. Bring any user-provided tools and any samples you wish to test. Gloves will be provided for users.
-
Once training is completed, you will request room access to MSE-XRD by submitting a request to Systems.
-
-
Proximity Card Request for XRD
-
If you cannot enter the lab with your proximity card, your account may be expired (needs to be renewed yearly if non-ENGR student)
-
Send an email to facilities manager, Perry Cheung (pcheung@engr.ucr.edu), an email with your ENGR login indicating expired ENGR account
-
-
Charges and Billing
-
All services and instruments are accessible by advanced appointment on first-come-first-serve basis.
-
An online web-based reservation system should be used for scheduling by registered users, who have the relevant access privileges.
-
Minimum reservation time on any instrument is a 1/2 hour. There is no limit on the length of reservation. A maximum continuous reservation time may be imposed if the demand becomes significant.
-
Starting time for each session is the booking time on the FACES system.
-
Your usage will be billed based on your FACES reservations.
-
Not recording a session within one hour of concluding the use is subject to 2x the hourly rate penalty charge per incident for each hour not recorded.
-
If users are found in violation of the scheduling procedure twice within a 3-month period, their access will be revoked for up to 6 months.
-
-
Visitors and Guests
-
All visitors MUST complete the following 4 training modules via UC Learning and inform the lab manager prior to entering the lab as an EH&S requirement
-
Laboratory Safety Fundamentals
-
Hazardous Waste Management
-
Radiation Safety For Users of Radiation Producing Machines
-
Compressed Gas Safety
-
- E-mail or deliver printed copy of your visitor's training transcript to facilities manager (MSE 311)
-
-
Acknowledge MSE Fee-For-Service Facilities
- Please acknowledge the use of our instrumentation and services in any form of publication or presentation.
- Send references of published work that has utilized MSE Fee-For-Service Facility resources to the Lab Manager: pcheung@engr.ucr.edu
-
Suggested acknowledgement text:
"<Specific testing or characterization or analysis (e.g. Scanning electron microscopy)> was performed on <cite specific instrument type and model> in the MSE Fee-For-Service Facilities at UC Riverside."
- Please acknowledge the use of our instrumentation and services in any form of publication or presentation.
